Feature
Three core capacity options
Mitsubishi S6S diesel engine
Maximum listed lift height of 6,000 mm
LCD operator display
Model-specific dimensions and turning radius
500 mm load centre
DeltaLift 4-5 Ton Diesel Forklift
Reliable diesel-powered material handling across multiple load-capacity options.
Diesel 500 mm
Choose the model that matches your load, available operating space and application. The range includes compact units through to heavier-capacity options depending on site needs.
4,000 - 5,000 kg
LOAD CAPACITY
500 mm
LOAD CENTRE
6,000 mm
LIFT HEIGHT
Availability and configuration are confirmed during quotation. Model selection should be based on the actual load, load centre, aisle or yard space, lifting height and duty cycle.
Product Overview
The DeltaLift 4-5 Ton Diesel Forklift range is designed for heavier material-handling duties where capacity, stability and robust diesel performance are required. The CPCD40, CPCD45 and CPCD50 provide rated capacities of 4,000 kg, 4,500 kg and 5,000 kg respectively, all at a 500 mm load centre.
All listed models use the Mitsubishi S6S engine and share a 2,100 mm wheelbase, 2,350 mm overhead-guard height and 1,530 mm overall width. The catalogue lists a maximum lifting height of 6,000 mm, allowing the final mast to be selected around the site and stacking requirement.
The range is suited to operations that need a conventional counterbalance forklift for heavier palletised loads, loading and unloading, production support and yard handling on suitable surfaces. Delta Heavy Equipment can assess the load, lift height, manoeuvring space and operating environment before preparing the quotation.
Why it matters
Provides 4,000 kg, 4,500 kg and 5,000 kg rated models.
A common listed engine platform across the range.
Provides mast options for elevated load placement.
Presents key machine information within the operator area.
The listed range provides defined manoeuvring measurements.
Provides a clear catalogue rating basis.
Practical outcome
Allows the machine to be matched more closely to the actual load requirement.
Supports consistent technical review and service planning across models.
Supports stacking and loading tasks, subject to residual-capacity checks.
Helps the operator monitor machine status during use.
Helps assess access, aisle and yard-space suitability before purchase.
Supports correct comparison when actual load dimensions and attachments are known.
Configuration
Each quotation should identify the selected model and final configuration. The scope should state the engine, mast and lift height, fork dimensions, tyres, hydraulic controls, attachment requirements, operator-protection equipment, lighting, alarms and any optional accessories included in the price.
Delta Heavy Equipment can assist with model selection, quotation and after-sales requirements. Delivery, commissioning, operator familiarisation, maintenance, parts and other services should be shown clearly in the quotation rather than assumed to be included.
Safety and Operating Suitability
Only trained and authorised operators should use the forklift. The machine must be operated within the rated capacity shown on its data plate and according to the operator manual, site traffic plan and applicable safety requirements. Capacity can reduce as lift height, load centre and attachment offset increase.
Before operation, inspect the forklift and route, confirm that the floor or yard surface can support the loaded machine, secure the load and use the installed seat restraint and operator-protection systems correctly. Diesel exhaust must be managed through suitable ventilation and site controls.
Frequently Asked Questions
The available capacity depends on the selected range and model. Delta can help narrow the right option based on the actual load, lifting height and site conditions.
Ready to discuss your heavy-duty forklift requirements?
Request a quotation based on your load, lift height, operating environment and preferred configuration.
